Error Codes: Outdoor Units ESIE06-04
3–24 Part 3 – Troubleshooting
3
1
3
4
5
Troubleshooting
See also:
P "Check No.04" on page 3-51
P "Check No.06" on page 3-53
P "Check No.07" on page 3-55
P "Check No.09" on page 3-57
Caution Be sure to turn off power switch before connect or disconnect connector, or parts damage may be
occurred.
Abnormal
Check No. 7
Installation condition check
Change the air outlet grille
position.
Change the installation location.
Clean the heat exchanger.
Abnormal
Normal
Check No. 9
Outdoor fan check
Replace fan motor.
Repair the connector or fan
motor lead wires.
Check the installation space.
Check No. 4
Electronic expansion valve check
Abnormal
Judgment
Replace the electronic expansion
valve or coil.
Replace the PCB.
Normal
Check No. 6
Heat exchanger thermistor check
Abnormal
Normal
Judgment
Replace the heat exchanger
thermistor.
Replace PCB.
Normal
