Specifications ESIE06-04
1–8 Part 1 – System Outline
3
1
1
4
5
2.2 EWA(Y)Q005~007A*V3
Technical
specifications
The table below contains the technical specifications.
Specification EWAQ005AAV3P EWAQ006AAV3P EWAQ007AAV3P EWYQ005AAV3P EWYQ006AAV3P EWYQ007AAV3P
Capacity Cooling (min-nom-max) (1) 4.01-5.2-5.2 kW 4.01-6.0-6.0 kW 4.01-7.1-7.1 kW 4.01-5.2-5.2 kW 4.01-6.0-6.0 kW 4.01-7.1-7.1 kW
Cooling during heat recovery -
Heat recovery -
Heating (min-nom-max) (2) - 4.5-6.1-7.27 kW 4.5-6.8-8.58 kW 4.5-8.2-9.18 kW
Heating (min-nom-max) (3) - 4.09-5.85-6.83 kW 4.09-6.35-8.13 kW 4.09-7.75-8.73 kW
Capacity steps -
Input Cooling (nom) 1.89 kW 2.35 kW 2.95 kW 1.89 kW 2.35 kW 2.95 kW
Heat recovery -
Heating (nom) (2) - - - 1.60 kW 1.84 kW 2.36 kW
Heating (nom) (3) - - - 1.97 kW 2.24 kW 2.83 kW
Vivrelec conditions
EER & COP EER 2.75 2.55 2.41 2.75 2.55 2.41
COP (2) - - - 3.81 3.70 3.47
COP (3) - - - 2.87 2.83 2.74
Casing Colour Ivory white
Material Polyester painted galvanised steel
Dimensions Unit - height 805 mm
Unit - width 1190 mm
Unit - depth 360 mm
Unit with packing - height 915 mm
Unit with packing - width 1265 mm
Unit with packing - depth 442 mm
Weight Machine weight 100 kg
Operating weight 104 kg
Gross weight 108 kg
Water heat exchanger Type Brazed plate
Filter - Type Brass Y-strainer
Filter - Diameter perforations 1 mm
Minimum water volume in the
system
10 l
Water flow rate - min. 12 l/min 12 l/min 12 l/min 12 l/min 12 l/min 12 l/min
Water flow rate - max. - - - - - -
Nominal water flow - cooling 14.9 l/min 17.2 l/min 20.4 l/min 14.9 l/min 17.2 l/min 20.4 l/min
Nominal water flow - heating - - - 17.5 l/min 19.5 l/min 23.5 l/min
Nominal water pressure drop:
- Cooling - Heat exchanger - - - - - -
- Cooling - Filter - - - - - -
- Cooling - Total - - - - - -
- Heating - Heat exchanger - - - - - -
- Heating - Filter ------
- Heating - Total ------
Insulation material PE foam
Model ACH30-48
Model quantity 1
Air heat exchanger Type Tube type
Rows 2
Stages 32
Fin pitch 1.8 mm
Face area -
