D -808 C – 08/01 A – EN Pag. 13/72
Table 7 - EWWQ 440-C22 AJYNN/A - Technical Data
TECHNICAL SPECIFICATIONS EWWQ – AJYNN/A C14 C15 C16 C18 C19
Capacity Cooling kW 1397 1479 1605 1769 1901
Type Stepless
Capacity control
Minimum capacity % 12.5 12.5 12.5 12.5 12.5
Unit power input Cooling kW 275 292 321 356 390
EER 5.08 5.07 4.99 4.96 4.87
ESEER 5.98 5.93 5.67 5.71 5.48
Colour RAL7032
Casing
Material Galvanized and painted steel sheet
Height mm 2453 2453 2547 2547 2547
Width mm 1350 1350 1350 1350 1350
Dimensions Unit
Depth mm 4985 4985 4844 4844 4809
Unit kg 4919 4969 5117 5177 5388
Weight
Operating Weight kg 5546 5606 5794 5843 6110
Type Shell and tubes
Water volume l 551 551 495 484 535
Nominal water flow
rate
Cooling l/s 66.7 70.7 76.7 84.5 90.8
Nominal Water
pressure drop
Cooling kPa 71 79 74 94 96
Water heat exchanger
Evaporator
Insulation material Closet cell foam elastomer
Type Shell and tubes
Number of condensers No. 2 2 2 2 2
Water volume l
1)75
2)86
1)86
2)86
1)91
2)91
1)91
2)91
1)91
2)91
Nominal water flow
rate
Cooling l/s
1)37.6
2)42.3
1)42.3
2)42.3
1)46.0
2)46.0
1)45.7
2)55.8
1)54.7
2)54.7
Nominal Water
pressure drop
Nominal Water
pressure drop
kPa
1)50.7
2)48.4
1)48.4
2)48.4
1)45
2)45
1)45
2)65
1)63
2)63
Water heat exchanger
Condenser
Insulation Material Expanded elastomer
Type Semi-hermet. single screw compr.
Oil charge l 32 32 32 32 32
Compressor
Quantity 2 2 2 2 2
Sound Power Cooling dBA 106.1 106.5 105.8 106.2 106.6
Sound level
Sound Pressure Cooling dBA 87 87 86 87 87
Refrigerant type
R410A R410A R410A R410A
R410
A
Refrigerant charge kg
1)120
2)120
1)120
2)120
1)130
2)130
1)130
2)130
1)130
2)130
Refrigerant circuit
N. of circuits 2 2 2 2 2
Piping connections Evaporator water inlet/outlet mm 273 273 273 273 273
Pipino connections Condenser water inlet/outlet in 5” 5” 5” 5” 5”
Safety devices High pressure (pressure switch)
Safety devices Low pressure (pressure switch)
Safety devices Emergency stop
Safety devices High discharge temperature on the compressor
Safety devices Phase monitor
Safety devices Low pressure ratio
Safety devices High oil pressure drop
Safety devices Low oil pressure
Notes
Cooling capacity, unit power input in cooling and EER are based on the following conditions:
evaporator 12°C/7°C; condenser 30/ 35°C.
