D -808 C – 08/01 A – EN Pag. 38/72
Table 13 – Electrical data EWWQ – AJYNN/A Unit
Unit Compressors Control
Size of
unit
Max.
current for
wires
sizing (1)
Max. startup
current (2)
Power
factor (3)
Size of
disconnecting
switch
Short-circuit
current
Icc
Number of
compressors
Max. current of compressors
Circ.1/ Circ.2
Peak current of compressors
Circ.1/ Circ.2
Size of type gG NH0/NH1
compressor fuses Circ.1/
Circ.2
A
A
A
kA
A A A A A A VA A
440 195 455 0.85 400 A 25 1 189 455 250 500 4
550 232 455 0.87 400 A 25 1 225 455 250 500 4
650 282 455 0.89 400 A 25 1 274 455 315 500 4
750 320 455 0.90 400 A 25 1 310 455 355 500 4
800 348 656 0.89 630 A 25 1 325 656 355 500 4
950 414 656 0.90 630 A 25 1 388 656 500 500 4
C10 464 636 0.87 630 A 25 2 225 225 455 455 250 250 500 4
C11 486 656 0.91 630 A 25 1 458 656 630 500 4
C12 514 674 0.88 630 A 25 2 225 274 455 455 250 315 500 4
C13 566 674 0.89 800 A 25 2 274 274 455 455 315 315 500 4
C14 603 702 0.89 800 A 25 2 274 310 455 455 315 355 500 4
C15 639 702 0.90 800 A 25 2 310 310 455 455 355 355 500 4
C16 692 925 0.89 800 A 25 2 325 325 656 656 355 355 500 4
C18 758 979 0.89 800 A 25 2 325 388 656 656 355 500 500 4
C19 824 979 0.90 1000 A 25 2 388 388 656 656 500 500 500 4
C20 895 1032 0.91 1000 A 25 2 388 458 656 656 500 630 500 4
C22 965 1032 0.91 1000 A 25 2 458 458 656 656 630 630 500 4
(1) FLA compressors
(2) Start-up current of the biggest compressor + 75% of the other compressor’s nominal current
(3) Power factor of compressors under nominal conditions (12/7°C – 30/35°C – 400V)
