D -808 C – 08/01 A – EN Pag. 19/72
Fig. 2 - Lifting the unit
CAUTION
Both the lifting ropes and the spacing bar and/or scales must be strong enough to support the machine safely.
Please check the unit’s weight on the machine’s nameplate.
The weights shown in the "Technical data" tables in the "General Information" chapter refer to standard units.
Some specific machines might have accessories that increase their overall weight (heat recovery, etc.)
CAUTION
The machine must be lifted with the utmost attention and care. Avoid jolting when lifting and lift the machine very
slowly, keeping it perfectly level.
