D -808 C – 08/01 A – EN Pag. 16/72
Operating limits
Storing
The units of the series can be stored under the following environmental conditions:
Minimum ambient temperature : -20°C
Maximum ambient temperature : 41°C
Max. R.H. : 95% not condensing
CAUTION
Storing below the minimum temperature mentioned above may cause damage to components such as the electronic
controller and its LCD display.
CAUTION
Storing above the maximum temperature may cause opening of the safety valves on the compressor’s suction line.
CAUTION
Storing in condensing atmosphere may damage the electronic components.
Operation
Operation is allowed within the limits mentioned in the following diagrams.
CAUTION
Operation outside the mentioned limits may damage the unit.
In case of doubt, contact the manufacturer.
