D -808 C – 08/01 A – EN Pag. 37/72
Table 12 – Electrical data EWWQ-AJYNN Unit
Unit Compressors Control
Size of
unit
Max.
current for
wires
sizing
Max. startup
current (1)
Power
factor (2)
Size of
disconnecting
switch
Short-circuit
current
Icc
Number of
compressors
Max. current of compressors
Circ.1/ Circ.2
(3)
Peak current of compressors
Circ.1/ Circ.2
Size of type gG NH0/NH1
compressor fuses Circ.1/
Circ.2
A
A
A kA
A A A A A A VA A
400 197 455 0.85 400 A 25 1 189 455 250 500 4
480 235 455 0.87 400 A 25 1 225 455 250 500 4
600 286 455 0.89 400 A 25 1 274 455 315 500 4
650 324 455 0.90 400 A 25 1 238 455 355 500 4
750 357 656 0.89 630 A 25 1 325 656 355 500 4
850 394 610 0.85 630 A 25 2 189 189 455 455 250 250 500 4
C11 419 656 0.90 630 A 25 1 388 656 500 500 4
800 432 638 0.86 630 A 25 2 189 225 455 455 250 250 500 4
900 470 638 0.87 630 A 25 2 225 225 455 455 250 250 500 4
C10 489 656 0.92 630 A 25 1 458 656 630 500 4
C12 522 676 0.88 630 A 25 2 225 274 455 455 250 315 500 4
C13 574 676 0.89 800 A 25 2 274 274 455 455 315 315 500 4
C14 611 705 0.90 800 A 25 2 274 310 455 455 315 355 500 4
C15 648 705 0.90 800 A 25 2 310 310 455 455 355 355 500 4
C16 715 933 0.89 800 A 25 2 325 325 656 656 355 355 500 4
C17 778 984 0.90 800 A 25 2 325 388 656 656 355 500 500 4
C18 840 984 0.90 1000 A 25 2 388 388 656 656 500 500 500 4
C19 906 1035 0.91 1000 A 25 2 388 458 656 656 500 630 500 4
C20 975 1035 0.92 1000 A 25 2 458 458 656 656 630 630 500 4
(1) Start-up current of the biggest compressor + current at 75% of the other compressors at maximum conditions
(2) Power factor of compressors under nominal conditions (12/7°C – 30/35°C – 400V)
(3) FLA compressors
