D -808 C – 08/01 A – EN Pag. 7/72
TECHNICAL SPECIFICATIONS
Table 1 – EWWQ 400-C20 AJYNN - Technical Data
TECHNICAL SPECIFICATIONS EWWQ - AJYNN 400 480 600 650 750
Capacity Cooling kW 388 474 574 651 742
Type Stepless
Capacity control
Minimum capacity % 25 25 25 25 25
Unit power input Cooling kW 87 106 130 148 170
EER 4.44 4.46 4.40 4.41 4.37
ESEER 4.95 4.98 4.97 4.97 4.72
Colour RAL7032
Casing
Material Galvanized and painted steel sheet
Height mm 1846 1846 2000 2000 1846
Width mm 1140 1140 1276 1276 1316
Dimensions Unit
Depth mm 3431 3431 3440 3440 3561
Unit kg 1933 1967 2283 2332 2407
Weight
Operating Weight kg 2135 2169 2543 2628 2777
Type Shell and tubes
Water volume l 124 118 176 170 274
Nominal water flow
rate
Cooling l/s 18.5 22.7 27.4 31.1 35.4
Nominal Water
pressure drop
Cooling kPa 49 65 45 48 55
Water heat exchanger
Evaporator
Insulation material Closet cell foam elastomer
Type Shell and tubes
Number of condensers No. 1 1 1 1 1
Water volume l 79 92 84 126 97
Nominal water flow
rate
Cooling l/s 22.9 27.9 33.9 38.5 43.9
Nominal Water
pressure drop
Cooling kPa 60 64 68 66 16
Water heat exchanger
Condenser
Insulation Material Expanded elastomer
Type Semi-hermet. single screw compr.
Oil charge l 16 16 16 16 16
Compressor
Quantity 1 1 1 1 1
Sound Power Cooling dBA 100.2 101.1 102.3 102.3 101.5
Sound level
Sound Pressure Cooling dBA 82 83 84 84 83
Refrigerant type
R410A
R410
A
R410A R410A R410A
Refrigerant charge kg 80 80 90 90 100
Refrigerant circuit
N. of circuits 1 1 1 1 1
Piping connections Evaporator water inlet/outlet mm 168.3 168.3 219.1 219.1 219.1
Piping connections Condenser water inlet/outlet in 5” 5” 5” 5” 6”
Safety devices High pressure (pressure switch)
Safety devices Low pressure (pressure switch)
Safety devices Emergency stop
Safety devices High discharge temperature on the compressor
Safety devices Phase monitor
Safety devices Low pressure ratio
Safety devices High oil pressure drop
Safety devices Low oil pressure
Notes
Cooling capacity, unit power input in cooling and EER are based on the following conditions:
evaporator 12°C/7°C; condenser 30/ 35°C.
