D -808 C – 08/01 A – EN Pag. 14/72
Table 8 - EWWQ 440-C22 AJYNN/A - Technical Data
TECHNICAL SPECIFICATIONS EWWQ – AJYNN/A C20 C22
Capacity Cooling kW 2061 2196
Type Stepless
Capacity control
Minimum capacity % 12.5 12.5
Unit power input Cooling kW 426 461
EER 4.84 4.77
ESEER 5.50 5.38
Colour RAL7032
Casing
Material Galvanized and painted steel sheet
Height mm 2547 2547
Width mm 1350 1350
Dimensions Unit
Depth mm 4809 4809
Unit kg 5408 5414
Weight
Operating Weight kg 6118 6124
Type Shell and tubes
Water volume l 527 527
Nominal water flow
rate
Cooling l/s 98.5 104.9
Nominal Water
pressure drop
Cooling kPa 119 134
Water heat exchanger
Evaporator
Insulation material Closet cell foam elastomer
Type Shell and tubes
Number of condensers No. 2 2
Water volume l
1)91
2)91
1)91
2)91
Nominal water flow
rate
Cooling l/s
1)54.6
2)64.2
1)63.5
2)63.5
Nominal Water
pressure drop
Nominal Water
pressure drop
kPa
1)54
2)83
1)82
2)82
Water heat exchanger
Condenser
Insulation Material Expanded elastomer
Type Semi-hermet. single screw compr.
Oil charge l 32 32
Compressor
Quantity 2 2
Sound Power Cooling dBA 107.1 107.5
Sound level
Sound Pressure Cooling dBA 88 88
Refrigerant type
R410A R410A
Refrigerant charge kg 130 130
Refrigerant circuit
N. of circuits 2 2
Piping connections Evaporator water inlet/outlet mm 273 273
Piping connections Condenseer water inlet/outlet in 5” 5”
Safety devices High pressure (pressure switch)
Safety devices Low pressure (pressure switch)
Safety devices Emergency stop
Safety devices High discharge temperature on the compressor
Safety devices Phase monitor
Safety devices Low pressure ratio
Safety devices High oil pressure drop
Safety devices Low oil pressure
Notes
Cooling capacity, unit power input in cooling and EER are based on the following conditions:
evaporator 12°C/7°C; condenser 30/ 35°C.
