D -808 C – 08/01 A – EN Pag. 8/72
Table 2 - EWWQ 400-C20 AJYNN - Technical Data
TECHNICAL SPECIFICATIONS EWWQ - AJYNN 800 850 900 C10 C11
Capacity Cooling kW 813 880 891 980 1028
Type Stepless
Capacity control
Minimum capacity % 25 25 12.5 12.5 12.5
Unit power input Cooling kW 175 206 194 213 245
EER 4.64 4.26 4.59 4.60 4.19
ESEER 5.37 4.60 5.36 5.34 4.53
Colour RAL7032
Casing
Material Galvanized and painted steel sheet
Height mm 2170 1846 2170 2170 1846
Width mm 1350 1316 1350 1350 1335
Dimensions Unit
Depth mm 4902 3561 4902 4902 3561
Unit kg 3921 2427 3949 3988 2457
Weight
Operating Weight kg 4422 2795 4463 4496 2812
Type Shell and tubes
Water volume l 344 266 344 325 251
Nominal water flow
rate
Cooling l/s 38.8 42.0 42.6 46.8 49.1
Nominal Water
pressure drop
Cooling kPa 54 50 64 59 57
Water heat exchanger
Evaporator
Insulation material Closet cell foam elastomer
Type Shell and tubes
Number of condensers No. 2 1 2 2 1
Water volume l
1)79
2)79
102
1)79
2)92
1)92
2)92
104
Nominal water flow
rate
Cooling l/s
1)23.8
2)23.8
52.3
1)23.8
2)28.5
1)28.7
2)28.7
61.3
Nominal Water
pressure drop
Nominal Water
pressure drop
kPa
1)64
2)64
20
1)64
2)67
1)68
2)68
26
Water heat exchanger
Condenser
Insulation Material Expanded elastomer
Type Semi-hermet. Single screw compr.
Oil charge l 32 16 32 32 16
Compressor
Quantity 2 1 2 2 1
Sound Power Cooling dBA 104.7 102.3 104.7 105.1 103.2
Sound level
Sound Pressure Cooling dBA 84 85 85 85 86
Refrigerant type
R410A R410A R410A R410A R410A
Refrigerant charge kg
1)85
2)85
100
1)85
2)85
1)85
2)85
100
Refrigerant circuit
N. of circuits 2 1 2 2 1
Piping connections Evaporator water inlet/outlet mm 219.1 219.1 219.1 219.1 219.1
Piping connections Condenser water inlet/outlet in 5” 6" 5” 5” 6”
Safety devices High pressure (pressure switch)
Safety devices Low pressure (pressure switch)
Safety devices Emergency stop
Safety devices High discharge temperature on the compressor
Safety devices Phase monitor
Safety devices Low pressure ratio
Safety devices High oil pressure drop
Safety devices Low oil pressure
Notes
Cooling capacity, unit power input in cooling and EER are based on the following conditions:
evaporator 12°C/7°C; condenser 30/ 35°C.
