![Daikin EWWQC15AJYNN/A Инструкция по монтажу онлайн [43/72] 531841](/views2/1658954/page43/bg2b.png)
D -808 C – 08/01 A – EN Pag. 43/72
WL1ST1
EVAPO RATOR
WL2
ST2
EX8
ELECTRO NIC
EXP. VALVE
EX8
ELECTRO NIC
EXP. VALVE
EVAPORATOR
HEATER
WATER
IN LET
WATER
OUTLET
Y5
Y6
Fig. 19 - Refrigeration cycle of the EWWQ – AJYNN / EWWQ – AJYNN/A DUAL Fr4 unit
LOW PRESSURE SWITCH
HIGH PRESSURE SWITCH
F12-22 LP
F13-23 HP
LOW PRESSURE TRANSDUCER (0 ÷ 30 bar)
HIGH PRESSURE TRANSDUCER (0 ÷ 45 bar)
LEAVING WATER TEMPERATURE
ENTERING WATER TEMPERATURE
WH1- 2
WOE
WL1- 2
WI E
OIL TEMPERATURE
WD1- 2
ST1-2
SUCTION TEMPERATURE
