Hardware Installation - 12 -

1-2 Product Specications

System

Dimension

 2U

 438mm (W) x 87.5mm (H) x 820mm (D)

CPU  2nd Generation Intel® Xeon® Scalable Processors

 Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon®

Silver Processor and Intel® Xeon® Bronze Processor

 System TDP up to 165W

NOTE! If only 1 CPU is installed, some PCIe or memory functions might be

unavailable

Socket  2 x LGA 3647

 Socket P

Chipset

 Intel® C622 Express Chipset

Memory  12 x DIMM slots

 DDR4 memory supported only

 6-channel memory architecture

 RDIMM modules up to 64GB supported

 LRDIMM modules up to 128GB supported

 1.2V modules: 2933/2666/2400 MHz

NOTE!

Memory frequency 2933MHz is for 2nd Generation Intel® Xeon® Scalable

Processors only

LAN  2 x 10Gb/s BASE-T LAN ports (1 x Intel® X557-AT2)

 2 x 1Gb/s LAN ports

 1 x 10/100/1000 management LAN

Expansion Slot • 4 x PCIe x16 slots (Gen3 x16 bus) for GPUs ( Slot_1 / Slot_3 / Slot_5 /

Slot_7)

Pre-installed CRSG02A in each slot

• Slot_2: 1 x PCIe x8 (Gen3 x8 bus) slot from CPU_0, shared with

M.2 PCIe x4 bus

• Slot_6: 1 x PCIe x16 (Gen3 x16 bus) slot from CPU_1

• 2 x M.2 slots:

- M-key

- PCIe Gen3 x4 per slot

- Supports NGFF-22110/2280 cards

- From CPU_0

- System is validated for population with a uniform GPU model

- Support is not provided for mixed GPU populations
