Gigabyte G241-G40 (rev. 100) [26/117] 3 removing the heat sink

System Hardware Installation - 26 -

3-3 Removing the Heat Sink

Follow these instructions to remove/install the fan duct:

1. Loosen the captive screws securing the heatsink in place in reverse order (4

1).

2. Lift and remove the heat sink from the system.

3. To reinstall the heat sink reverse steps 1-2 while ensuring that you tighten the captive screws in

sequential order (1

4) as seen in the image below.

CPU1 Heat Sink
