Gigabyte G241-G40 (rev. 100) [88/117] 3 8 miscellaneous configuration

- 88 - BIOS Setup

5-3-8 Miscellaneous Conguration

Parameter

Description

Miscellaneous Conguration

Active Video

Selects the active video type.

Options available: Auto, Onboard Device, PCIE Device. Default setting is

Auto.
