- 72 - BIOS Setup

Parameter

Description

Enter Conguration Menu

Press [Enter] to congure advanced items.



Create new VLAN



VLAN ID

– Sets VLAN ID for a new VLAN or an existing VLAN.

– Press the <+> / <-> keys to increase or decrease the desired values.

– The valid range is from 0 to 4094.



Priority

– Sets 802.1Q Priority for a new VLAN or an existing VLAN.

– Press the <+> / <-> keys to increase or decrease the desired values.

– The valid range is from 0 to 7.



Add VLAN

– Press [Enter] to create a new VLAN or update an existing VLAN.



Congured VLAN List



Remove VLAN

– Press [Enter] to remove an existing VLAN.
