- 81 - BIOS Setup
Parameter
Description
Interleave NVDIMMs
Controls if NVDIMMs are interleaved together or not.
Options available: Enable/Disable. Default setting is Disable.
Assert ADR on Reset
Enable/Disable Assert ADR on Reset.
Options available: Enable/Disable. Default setting is Disable.
Assert ADR on S5
Enable/Disable Assert ADR on S5.
Options available: Enable/Disable. Default setting is Disable.
Memory Topology
Press [Enter] to view memory topology with DIMM population
information.
Memory Map
Press [Enter] to congure advanced items.
IMC Interleaving
– controls the interleaving between the Integrated Memory
Controllers (IMCs).
– Options available: Auto, 1-way Interleave, 2-way Interleave.
Default setting is Auto.
Memory RAS Conguration
Press [Enter] to congure advanced items.
RAS Type
– Displays the RAS type.
Static Virtual Lockstep Mode
– Enable/Disable the Static Virtual Lockstep mode.
– Options available: Disable/Enable. Default setting is Disable.
Mirror Mode
– Mirror Mode will set entire 1LM/2LM memory in system to be
mirrored, consequently reducing the memory capacity by half.
Enables the Mirror Mode will disable the XPT Prefetch.
– Options available: Disable/Enable Mirror Mode (1LM). Default
setting is Disable.
Memory Rank Sparing
– Enable/Disable Memory Rank Sparing. This feature is only
available on 1LM.
– Options available: Disable/Enable. Default setting is Disable.
Correctable Error Threshold
– Correctable Error Threshold (1-32767) used for sparing, tagging,
and leaky bucket.
– Press the <+> / <-> keys to increase or decrease the desired
values.
SDDC Plus One
– Enable/Disable SDDC Plus One.
– Options available: Disable/Enable. Default setting is Disable.
