- 95 - BIOS Setup

Parameter

Description

OS Wtd Timer

Policy

Congure OS Watchdog Timer Policy.

Options available: Reset, Do Nothing, Power Down, Power Cycle. Default setting is

Reset.

Please note that this item is congurable when OS Watchdog Timer is set to

Enabled.

Wait BMC Ready

POST wait BMC ready and reboot system.

Options available: Disabled, 2 minutes, 4 minutes, 6 minutes.

Default setting is 2 minutes.

System Event Log

Press [Enter] to congure advanced items.

View FRU

Information

Press [Enter] to view the advanced items.

BMC VLAN

Conguration

Press [Enter] to congure advanced items.

BMC network

conguration

Press [Enter] to congure advanced items.

IPv6 BMC Network

Conguration

Press [Enter] to congure advanced items.
