Fatal1ty X299 Gaming K6 Series
Bahasa Indonesia
** Jika slot PCIE4 digunakan, maka slot M2_2 mendukung modul M.2
PCI Express hingga Gen3 x2 (16 Gb/s)
•
Mendukung AMD Quad CrossFireX
TM
, 3-Way CrossFireX
TM
, dan
CrossFireX
TM
***
•
Mendukung NVIDIA® Quad SLI
TM
, 3-Way SLI
TM
dan SLI
TM
***
*** 3-Way CrossFireX
TM
dan 3-Way SLI
TM
hanya didukung oleh CPU
44 jalur.
•
15μ Bidang Kontak berwarna Emas di Slot VGA PCIe (PCIE1 dan
PCIE3)
Audio
•
Audio HD 7.1 CH dengan Perlindungan Konten (Realtek
ALC1220 Audio Codec)
•
Mendukung Audio Blu-ray Premium
•
Mendukung Perlindungan dari Arus Pendek
•
Nichicon Fine Gold Series Audio Caps
•
120dB SNR DAC dengan Amplier Diferensial
•
TI® NE5532 Premium Headset Amplier untuk Konektor Audio
Panel Depan (Mendukung headset hingga 600 Ohm)
•
Daya Masuk Kuat
•
Teknologi Direct Drive
•
Pelindung Terisolasi PCB
•
Deteksi Impedansi pada port Output Depan
•
Lapisan PCB Individual untuk Saluran Audio Ka/Ki
•
Konektor Audio Emas 15μ
•
Mendukung Cinema3 SoundBlaster Creative
LAN
•
Gigabit LAN 10/100/1000 Mb/s
•
1 x Giga PHY Intel® I219V, 1 x GigaLAN Intel® I211AT
•
Mendukung Wake-On-LAN
•
Mendukung Perlindungan dari Petir/ESD
•
Mendukung Ethernet Hemat Energi 802.3az
•
Mendukung PXE
I/O Panel
Belakang
•
1 x Port Mouse/Keyboard PS/2
•
1 x Port SPDIF Out Optik
•
4 x Port USB 2.0 (Mendukung Perlindungan dari ESD)
* 1 x Port Mouse Fatal1ty (USB 2.0) disertakan
•
1 x USB 3.1 Port Tipe A (10 Gb/s) (ASMedia ASM3142)
(Mendukung Perlindungan ESD)
