ASRock Fatal1ty X299 Gaming K6 [6/200] English
![ASRock Fatal1ty X299 Gaming K6 [6/200] English](/views2/1686111/page6/bg6.png)
English
2
No. Description
1 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
3 ATX 12V Power Connector (ATX12V1)
4 CPU Fan / Waterpump Fan Connector (CPU_OPT/W_PUMP1)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_C2, DDR4_D2)
6 2 x 288-pin DDR4 DIMM Slots (DDR4_C1, DDR4_D1)
7 CPU Fan Connector (CPU_FAN1)
8 RGB LED Header (RGB_LED2)
9 ATX Power Connector (ATXPWR1)
10 Virtual RAID On CPU Header (VROC1)
11 USB 3.0 Header (USB3_5_6)
12 USB 3.0 Header (USB3_7_8)
13 SATA3 Connectors (SATA3_0_1)
14 SATA3 Connectors (SATA3_2_3)
15 SATA3 Connectors (SATA3_4_5)
16 SATA3 Connectors (SATA3_6_7)
17 Power LED and Speaker Header (SPK_PLED1)
18 Chassis Fan Connector (CHA_FAN1)
19 System Panel Header (PANEL1)
20 Chassis Fan / Waterpump Fan Connector (CHA_FAN3/W_PUMP2)
21 USB 2.0 Header (USB_9_10)
22 USB 2.0 Header (USB_7_8)
23 USB 2.0 Header (USB_5_6)
24 TPM Header (TPMS1)
25 underbolt AIC Header (TB1)
26 RGB LED Header (RGB_LED1)
27 Clear CMOS Jumper (CLRMOS1)
28 Front Panel Audio Header (HD_AUDIO1)
29 Chassis Fan Connector (CHA_FAN2)
