5
Fatal1ty X299 Gaming K6 Series
Chapter 1 Introduction
ank you for purchasing ASRock Fatal1ty X299 Gaming K6 Series motherboard,
a reliable motherboard produced under ASRock’s consistently stringent quality
control. It delivers excellent performance with robust design conforming to
ASRock’s commitment to quality and endurance.
1.1 Package Contents
•
ASRock Fatal1ty X299 Gaming K6 Series Motherboard (ATX Form Factor)
•
ASRock Fatal1ty X299 Gaming K6 Series Quick Installation Guide
•
ASRock Fatal1ty X299 Gaming K6 Series Support CD
•
1 x I/O Panel Shield
•
1 x ASRock SLI_HB_Bridge_2S Card (Optional)
•
1 x ASRock 3-Way SLI-2S1S Bridge Card (Optional)
•
4 x Serial ATA (SATA) Data Cables (Optional)
•
3 x Screws for M.2 Sockets (Optional)
Because the motherboard specications and the BIOS soware might be updated, the
content of this documentation will be subject to change without notice. In case any modi-
cations of this documentation occur, the updated version will be available on ASRock’s
website without further notice. If you require technical support related to this mother-
board, please visit our website for specic information about the model you are using. You
may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock
website http://www.asrock.com.
