English
25
Fatal1ty X299 Gaming K6 Series
5
1
8
4
ATX 12V Power
Connector
(8-pin ATX12V1)
(see p.1, No. 3)
is motherboard
provides an 8-pin ATX
12V power connector. To
use a 4-pin ATX power
supply, please plug it along
Pin 1 and Pin 5.
TPM Header
(17-pin TPMS1)
(see p.1, No. 24)
is connector supports Trusted
Platform Module (TPM) system,
which can securely store keys,
digital certicates, passwords,
and data. A TPM system also
helps enhance network security,
protects digital identities, and
ensures platform integrity.
underbolt AIC
Connector
(5-pin TB1)
(see p.1, No. 25)
Please connect a underbolt™
add-in card (AIC) to this
connector via the GPIO cable.
RGB LED Headers
(4-pin RGB_LED1)
(see p.1, No. 26)
(4-pin RGB_LED2)
(see p.1, No. 8)
ese two RGB headers are used
to connect RGB LED extension
cable which allows
users to choose from various LED
lighting eects.
Caution: Never install the RGB
LED cable in the wrong orienta-
tion; otherwise, the cable may
be damaged.
*Please refer to page 34 for
further instructions on these two
headers.
12V GRB
1
12V
G
R
B
1
1
GN D
SM B_DATA_MAIN
L A D2
L A D1
GN D
S_ PWRDWN #
SE RIRQ #
GN
D
P CICL K
P CIRST #
L A D3
+3 V
L A D0
+3VS B
GN D
FR AM E
SM B_CLK_MAIN
1
