193
Fatal1ty X299 Gaming K6 Series
Bahasa Indonesia
•
1 x Konektor Kipas CPU (4-pin)
* Konektor Kipas CPU mendukung kipas CPU dengan daya kipas
maksimum 1A (12W).
•
1 x Konektor Kipas CPU Opsional/Pompa Air (4-pin)
* CPU Opsional/Kipas Pompa Air mendukung kipas berpendingin
air dengan daya kipas maksimum 1,5A (18W).
•
2 x Konektor Kipas Chassis (4-pin) (Kontrol Kecepatan Kipas
Pintar)
•
1 x Konektor Sasis Opsional/Kipas Pompa Air (4-pin)
* Sasis Opsional/Kipas Pompa Air mendukung kipas berpendingin
air dengan daya kipas maksimum 1,5A (18W).
* CHA_FAN1 dan CHA_FAN2 dapat mendeteksi otomatis jika kipas
3-pin atau 4-pin sedang digunakan.
•
1 x Konektor Daya ATX 24-pin (Konektor Daya dengan Kerapa-
tan Tinggi)
•
1 x Konektor Daya 12 V 8-pin (Konektor Daya dengan Kerapatan
Tinggi)
•
1 x Konektor Audio Panel Depan (15μ Konektor Audio Emas)
•
1 x Konektor underbolt AIC (5-pin)
•
3 x Header USB 2.0 (Mendukung 6 port USB 2.0) (Mendukung
Perlindungan dari ESD)
•
2 x Header USB 3.0 (Mendukung 4 port USB 3.0) (Hub ASMedia
ASM1074) (Mendukung Perlindungan dari ESD)
•
1 x Dr. Debug disertai LED
Fitur BIOS
•
2 x AMI UEFI Legal BIOS dengan dukungan GUI multibahasa (1
x BIOS Utama dan 1 x BIOS Cadangan)
•
Mendukung Teknologi Pencadangan Aman UEFI
•
ACPI 6.1 Kompatibel dengan aktivitas pengaktifan
•
Dukungan SMBIOS 3.0
•
Multipengatur Tegangan CPU, DRAM, VPPM, VTTM, PCH 1,0V,
VCCMPHY, VCCIO, VCCST, VCCSA, VCCSFR, VCCPLL, CLK
VDD, PEGRCOMP
