ASRock 4Core1333-eSATA2 Motherboard

2.122.12

2.12

Serial ASerial A

Serial A

A (SAA (SA

A (SA

A) / Serial AA) / Serial A

A) / Serial A

AII (SAAII (SA

AII (SA

AII) Hard DisksAII) Hard Disks

AII) Hard Disks

InstallationInstallation

Installation

This motherboard adopts Intel

ICH7R south bridge chipset that supports Serial

ATA (SATA) / Serial ATAII (SATAII) hard disks and RAID (RAID 0, RAID 1, RAID 10,

RAID 5, and Intel Matrix Storage) functions. You may install SATA / SATAII hard

disks on this motherboard for internal storage devices. This section will guide you

to install the SATA / SATAII hard disks.

STEP 1: Install the SATA / SATAII hard disks into the drive bays of your chassis.

STEP 2: Connect the SATA power cable to the SATA / SATAII hard disk.

STEP 3: Connect one end of the SATA data cable to the motherboard’s SATAII

connector.

STEP 4: Connect the other end of the SATA data cable to the SATA / SATAII hard

disk.

1. If you plan to use RAID 0, RAID 1, or Intel Matrix Storage function, you

need to install at least 2 SATA / SATAII hard disks. If you plan to use

RAID 5 function, you need to install at least 3 SATA / SATAII hard disks.

If you plan to use RAID 10 function, you need to install at least 4 SATA /

SATAII hard disks.

2. It is not recommended to switch the “Configure SATA as” setting between

AHCI, RAID, and IDE mode after OS installation.
