Si34-704 Troubleshooting by Indication on the Remote Controller
Troubleshooting 237
Troubleshooting
The alarm indicator is displayed when the fan is being used also.
Note: 5 HP class ··· R3T
8~12 HP class ··· R31T, R32T
14, 16Hp class ··· R31T, R32T and R33T
∗
Refer to “Thermistor Resistance / Temperature Characteristics” table on P362.
(V3072)
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Resistance
is normal when
measured after
disconnecting the thermistor
R31, 32T or R33T from the
outdoor unit PC board.
(2.5kΩ to
1.3kΩ)
Replace outdoor unit PC board
(A1P).
Connect the connector and turn on
again.
NO
NO
Replace the thermistor (R31, 32T
or R33T)
YES
YES
Connector
is connected to X29A
of outdoor unit
PC board
(A1P).
Confirm which discharge
thermistor is abnormal using
outdoor unit "monitor mode".
(Refer page 194 and 195)
