38 | APPENDIX I: Specicaons in Other Languages
German
Spezikaonen
CPU-Unterstützung
Anschluss-1151 für Intel® Core i7 / i5 / i3 / Penum / Celeron Prozessor
Maximale CPU TDP (Thermal Design Power): 95 Wa
* Bie konsuleren Sie www.biostar.com.tw für CPU-Unterstützungsliste
Chipset
INTEL® Z270 (Z270GTN)
INTEL® B250 (B250GTN)
Festplaenspeicher
Z270GTN : Unterstützt zweikanaliges DDR4 1866/2133/2400/3200(OC)
B250GTN : Unterstützt zweikanaliges DDR4 1866/2133/2400
2x DDR4 DIMM-SpeicherSlot, Max. Uterstützung bis zu 32 GB-Speicher
Jedes DIMM unterstützt nicht-ECC 4/8/16 GB DDR4-Module
* DDR4-2400 für die Intel® Core ™ Prozessorfamilie der 7. Generaon.
* Bie konsuleren Sie www.biostar.com.tw für für Speicherunterstützung Liste.
Arbeitsspeicher
Z270GTN:
INTEL® Z270
4x SATA III-Verbindung (6Gb/s) : Unterstützt AHCI, RAID 0, 1, 5, 10 & Intel® Rapid Storage Technology
1x M.2 - Key M (32Gb/s) : Unterstützt PCI-E / SATA SSD & Intel® Optane Technology
1x U.2 (32Gb/s) : Unterstützt Intel® Optane Technology
B250GTN:
INTEL® B250
4x SATA III-Verbindung (6Gb/s) : Unterstützt AHCI
1x M.2 (32Gb/s) : Key M - Unterstützt PCI-E & SATA SSD
1x U.2 (32Gb/s) : Unterstützt Intel® Optane Technology
LAN
Intel i219V
10/ 100/ 1000 Mb Auto-Negoaon, Halb- / Voll-Duplex-fähig
Audio-Codec
ALC892
7.1 Kanäle, HD-Audio, Hi-Fi(Front)
USB
6x USB 3.0-Port (4 hintere I/Os und 2 via interne Header)
4x USB 2.0-Port (2 hintere I/Os und 2 via interne Header)
Erweiterungsanschlüsse 1x PCIe 3.0 x16-Slot
Hintere I/Os
1x PS/2-Maus / Keyboard
1x DVI-D-Port
1x HDMI-Port
4x USB 3.0-Port
2x USB 2.0-Port
1x LAN-Port
5x Audio Jack
1x S/PDIF out port
Interne I/Os
Z270GTN:
4x SATA III-Verbindung (6Gb/s)
1x U.2-Verbindung (32Gb/s)
1x M.2 - Key E-Slot : Unterstützt 2230 Wi-Fi
1x USB 2.0-Header (jeder Header unterstützt 2
USB 2.0-Ports)
1x USB 3.0-Header (jeder Header unterstützt 2
USB 3.0-Ports)
1x 8-Pin-Stromverbindung
1x 24-Pin-Stromverbindung
1x CPU-Venlatorverbindung
1x System-Venlatorverbindung
1x Header für Frontpanel
1x Header für Frontaudio
1x Header für klares CMOS
2x Header 5050 LED
B250GTN:
4x SATA III-Verbindung (6Gb/s)
1x U.2-Verbindung (32Gb/s)
1x USB 2.0-Header (jeder Header unterstützt 2
USB 2.0-Ports)
1x USB 3.0-Header (jeder Header unterstützt 2
USB 3.0-Ports)
1x 8-Pin-Stromverbindung
1x 24-Pin-Stromverbindung
1x CPU-Venlatorverbindung
1x System-Venlatorverbindung
1x Header für Frontpanel
1x Header für Frontaudio
1x Header für klares CMOS
2x Header 5050 LED
Formfaktor Mini-ITX Formfaktor, 170 mm x 170 mm
OS-Unterstützung
Windows 7 (32/64bit)/ 8.1(64bit) /10(64bit)
* Windows 7 (32/64 Bit) / 8.1 (64 Bit) für die Intel® Core ™ Prozessorfamilie der 6. Generaon.
* Biostar reserves the right to add or remove support for any OS with or without noce.
