第三章: UEFI BIOS和软件 | 23
Z270GTN & B250GTN
3�3 软件
安装软件
1. 将光盘放入光驱，若Autorun功能已激活，驱动安装程序将会出现。
2. 选择Software Installation，然后点击各软件图标。
3. 根据屏幕上的指令完成安装。
启动软件
安装程序完成后，桌面上将出现软件图标。请双击图标启动软件工具。
»
所 有 软 件 的 相 关 信 息 和 内 容 若 有 变 更，恕 不 另 行 通 知。为 使 系 统 性 能 更 佳，软 件 会 不 断 升 级。
»
下面的图片和信息仅供参考，此主板的实际信息和设置可能与手册稍有差异。
BIOScreen 工具
此实用工具可以将开机画面个性化。您可以选择BMP格式来自定义计算机开机画面。
请参照以下步骤来更新开机画面：
• 加载画面(Load Image)：选择图片作为开机画面。
• 转换(Transform)：转换图片并预览。
• 更新BIOS(Update Bios)：将图片写入BIOS内存，然后完成更新。
