40 | APPENDIX I: Specicaons in Other Languages
Spanish
Especicaciones
Compabilidad con el
procesador
Ranura 1151 para procesador Intel® Core i7 / i5 / i3 / Penum / Celeron
Alimentación de Proyección Térmica (TDP – Thermal Design Power): 95 Wa
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el procesador.
Tipo de Placa
INTEL® Z270 (Z270GTN)
INTEL® B250 (B250GTN)
Memoria
Z270GTN : Soporta DDR4 1866/2133/2400/3200(OC) Doble Canal
B250GTN : Soporta DDR4 1866/2133/2400 Doble Canal
2x DDR4 DIMM Ranura de memoria Soporta hasta 32 GB Memoria
Cada DIMM soporta un modulo non-ECC 4/8/16 GB DDR4
*DDR4-2400 para la familia de procesadores Intel® Core ™ de 7ª generación.
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el memoria.
Almacenamiento de
información
Z270GTN:
INTEL® Z270
Conector 4x SATA III (6Gb/s) : Soporta AHCI, RAID 0, 1, 5, 10 & Intel® Rapid Storage Technology
1x M.2 - Key M (32Gb/s) : Soporta PCI-E / SATA SSD & Intel® Optane Technology
1x U.2 (32Gb/s) : Soporta Intel® Optane Technology
B250GTN:
INTEL® B250
Conector 4x SATA III (6Gb/s) : Soporta AHCI
1x M.2 (32Gb/s) : Key M - Soporta PCI-E / SATA SSD
1x U.2 (32Gb/s) : Soporta Intel® Optane Technology
LAN
Intel i219V
10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio
ALC892
Canales Audio de Alta Denición 7.1, Hi-Fi(Front)
USB
Ranura 6x USB 3.0 (4 en las entrada/salidas posteriores y 2 por los distribuidores internos)
Ranura 4x USB 2.0 (2 en las entrada/salidas posteriores y 2 por los distribuidores internos)
Ranuras de Exnción Ranura 1x PCIe 3.0 x16
Panel trasero de E/S
Ratón / Teclado 1x PS/2
Ranura 1x DVI-D
Ranura 1x HDMI
Ranura 4x USB 3.0
Ranura 2x USB 2.0
Ranura 1x LAN
Socket audio 5x
Ranura 1x S/PDIF out
Conectores en placa
Z270GTN:
Conector 4x SATA III (6Gb/s)
Ranura 1x U.2 (32Gb/s)
1x M.2 - Key E : Soporta 2230 Wi-Fi
Distribuidor 1x USB 2.0 (cada distribuidor soporta 2
ranuras USB 2.0)
Distribuidor 1x USB 3.0 (cada distribuidor soporta 2
ranuras USB 3.0)
Conector con 8 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x1
Conector Venlador Sistema x1
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Distribuidor 5050 LED x2
B250GTN:
Conector 4x SATA III (6Gb/s)
Ranura 1x U.2 (32Gb/s)
Distribuidor 1x USB 2.0 (cada distribuidor soporta 2
ranuras USB 2.0)
Distribuidor 1x USB 3.0 (cada distribuidor soporta 2
ranuras USB 3.0)
Conector con 8 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x1
Conector Venlador Sistema x1
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Distribuidor 5050 LED x2
Factor de Forma Factor de Forma Mini-ITX, 170 mm x 170 mm
Soporte OS
Windows 7 (32/64bit)/ 8.1(64bit) /10(64bit)
* Windows 7 (32/64 bits) / 8.1 (64 bits) sólo para la familia de procesadores Intel® Core ™ de 6ª
generación.
* Biostar reserva su derecho de añadir o rerar el soporte para cada OS con o sin nocación.
