4 | 第一章: 主板介绍
1�3 主板特性
规格
CPU支援
Socket 1151，Intel Core i7 / i5 / i3 / Pentium / Celeron处理器
CPU最大热功耗(95Watt)
* 请访问 www.biostar.com.tw 获取CPU的支持列表
芯片组
INTEL® Z270 (Z270GTN)
INTEL® B250 (B250GTN)
内存
Z270GTN：支持双通道DDR4 1866/2133/2400/3200(OC)
B250GTN：支持双通道DDR4 1866/2133/2400
2个DDR4 DIMM插槽，最大内存容量为32GB
每个DIMM支持非ECC 4/ 8/ 16 GB DDR4内存模组
* DDR4-2400用于第7代Intel®Core™处理器系列。
* 请访问 www.biostar.com.tw 获取内存的支持列表。
存储器
Z270GTN：
INTEL® Z270
4个SATA III接口 (6Gb/s)：支持 AHCI, RAID 0，1，5，10 & Intel®快速储存技术
1个 M.2 - Key M (32Gb/s) : 支持 PCI-E / SATA SSD & Intel® Optane技术
1个 U.2 (32Gb/s)：支持 Intel® Optane技术
B250GTN：
INTEL® B250
4个SATA III接口 (6Gb/s)：支持 AHCI
1个 M.2 (32Gb/s)：Key M - 支持 PCI-E / SATA SSD
1个 U.2 (32Gb/s)：支持 Intel® Optane技术
网络
Intel i219V
10/ 100/ 1000 Mb/s自适应传输模式，半双工/全双工工作模式
音效 ALC892 8声道音频输出，支持高清音频，Hi-Fi (前)
USB
6个USB 3.0端口(背板4个端口，板载接头支持2个端口)
4个USB 2.0端口(背板2个端口，板载接头支持2个端口)
扩展槽 1个PCIe 3.0 x16插槽
背板接口
1个PS/2鼠标/键盘接口
1个DVI-D端口
1个HDMI端口
4个USB3.0端口
2个USB2.0端口
1个LAN端口
5个音频插孔
1个S/PDIF输出端口
板载接口
Z270GTN:
4个SATA III接口
1个U.2 端口
1个M.2 - Key E 端口 : 支持 2230 Wi-Fi
1个USB2.0接头(每个接头支持2个USB2.0端口)
1个USB3.0接头(每个接头支持2个USB3.0端口)
1个电源接口(8针)
1个电源接口(24针)
1个CPU风扇接头
1个系统风扇接头
1个前置面板接头
1个前置音频接头
1个清空CMOS数据接头
2个5050 LED接头
B250GTN:
4个SATA III接口
1个U.2 端口
1个USB2.0接头(每个接头支持2个USB2.0端口)
1个USB3.0接头(每个接头支持2个USB3.0端口)
1个电源接口(8针)
1个电源接口(24针)
1个CPU风扇接头
1个系统风扇接头
1个前置面板接头
1个前置音频接头
1个清空CMOS数据接头
2个5050 LED接头
主板尺寸 Mini-ITX Form Factor，170 mm x 170 mm
操作系统支持
Windows 7 (32/64bit)/ 8.1(64bit) /10(64bit)
* Windows 7（32/64位）/ 8.1（64位）仅适用于第6代Intel®Core™处理器系列。
* 如有增加或减少任何OS支持，Biostar保留不预先通知的权利。
