M
M
M
7
7
7
V
V
V
I
I
I
Z
Z
Z
11
Power Source Selection for Keyboard/ Mouse: JKBV1 (No support
for version 8.0)
JKBV1 Assignment Description
1
3
Pin 1-2 close
+5V
+5V for key board and mouse
1
3
Pin 2-3 close
+5V Standby
Voltage
PS/2 Mouse and PS/2 Key board ar
e
powered with +5V standby v oltage
Note: In order to support the function “power-on the system via keyboard and
mouse function, “JKBV1” jumper cap should be placed on pin 2-3.
Power Source Selection for USB: JUSBV1/ JUSBV2/ JUSBV3 (No
support for version 8.0)
JUSBV1/JUSBV2/
JUSBV3
Assignment Description
1 3
Pin 1-2 close
+5V JUSBV3: 5V f or USB at the 1394_USB
1
port connector
JUSBV2: 5V for USB at the JUSB2 por
t
connector
JUSBV1: 5V for USB at the JUSBLAN1
port connector
1 3
Pin 2-3 close
+5V Standby
Voltage
JUSBV3: J1394_USB1 port is powered
with standby voltage of 5V
JUSBV2: JUSB2 port is powered with
standby v oltage of 5V
JUSBV1: JUSBLAN1 port is powered
with standby voltage of 5V
Note: In order to support the function “power-on the system via USB devices
function, “JUSBV1/JUSBV2/ JUSBV3” jumper cap should be placed on pin
2-3 respectively.
