Caractéristiques de la M7VIZ
A. Maté ri e l
Processeur
Fournit un support Socket A.
Prend en charge un unique processeur AMD
®
de la f amille Athlon/ Duron.
Bus f ace avant à 200/266/333 MHz.
Chipset
Pont nord : VIA KM400.
Pont sud : VIA VT8235CE/ VT8237.(option)
Mémoire principale
Prend en charge 2 barrettes DDR.
Prise en charge des périphériques SPD DDR 200/266/333/400 MHz (sans ECC).
Taille maximale de mémoire : 2 Go.
Super E/S
Puce : Winbond W83697HF. (Version 1.3)
ITE8705F. (Version 8.0)
Expansion
Trois emplacements PCI 32 bits bus maître.
Un emplacement CNR. (Type B uniquement)
Un emplacement AGP 8X.
IDE intégré
Prend en charge quatre lecteurs de disques IDE.
Prend en charge les modes PIO 4, Maître et bus maître Ultra DMA 33/66/100/133.
Réseau
Puce : VIA VT6103.
Prend en charge la négociation automatique 10 Mb/s et 100 Mb/s
Capacité semi duplex/duplex complet.
Puce IEEE 1394 (Option, Version 8 .0 non prise en charge)
Puce : VIA VT6307.
Prend en charge 2 ports IEEE 1394.
Détecte les périphériques connectés et configure automatique la vitesse de
transf ert des données à 100, 200 ou 400 Mb/s.
Codec son AC’97 intégré
Puce : CMI9761A.
Conf orm e à la s pécif ic at ion AC ’97.
Prend en charge 6 canaux.
