Dépannage
PROBLÈME SOLUTION
Pas d'alimentation au système. Les voyants
lumineux ne s'allument pas, le ventilateur à
l'intérieur du bloc d'alimentation ne se met pas
en marche. Le voyant du clavier ne s'allume pas
* Assurez-vous
q
ue le câble d'alimentation es
bien branché
* Remplacez le câble
* Contactez le service d'assistance technique.
PROBLÈME SOLUTION
Le système ne fonctionne pas. Les voyants du
clavier sont allumés, les voyants de
l'alimentation aussi, le disque dur tourne.
* En exer
ç
ant une
p
ression uniforme sur le
s
deux extrémités du DIMM,
p
oussez le modul
e
vers le bas jusqu'à ce qu'il s'enclenche.
PROBLÈME SOLUTION
Le s
y
stème ne se réinitialise
p
as du dis
q
ue dur,
réinitialisation possible depuis le lecteur
CD-ROM.
* Vérifiez le câble du dis
q
ue à la carte d
u
contrôleur de disque. Assurez-vous
q
ue le
s
deux extrémités sont bien branchées ; vérifie
z
le t
yp
e de lecteur dans la confi
g
uratio
n
standard de CMOS.
* Il est très im
p
ortant d'effectuer de
s
sauvegardes du disque dur. Les dis
q
ues dur
s
peuvent tomber en panne à n'importe
q
ue
moment.
PROBLÈME SOLUTION
Le système ne se réinitialise que depuis le
CD-ROM. Le disque dur peut être lu et les
applications sont utilisables mais il est
impossible d'effectuer de réinitialisation depuis le
disque dur.
* Effectuez une sauvegarde des fichiers de
s
données et d'application. Reformatez l
e
disque dur. Ré-installez les a
pp
lications et le
s
données sauve
g
ardées sur les dis
q
ues d
e
secours.
PROBLÈME SOLUTION
Un message s'affiche indiquant que la
configuration n'est pas valide ou qu'il
y
a une
panne du CMOS.
* Vérifiez l'é
q
ui
p
ement du s
y
stème
Assurez-vous
q
ue les informations de l
a
configuration sont correctes.
PROBLÈME SOLUTION
Impossible de réinitialiser le système après
l'installation d'un deuxième disque dur.
* Réglez les cavaliers maître/esclav
e
correctement.
* Exécutez le
p
ro
g
ramme SETUP e
sélectionnez les types de lecteur. Contacte
z
les fabricants
p
our toute
q
uestion d
e
compatibilité avec les autres disques.
