Biostar M7VIZ [8/63] Package contents
![Biostar M7VIZ [8/63] Package contents](/views2/1711915/page8/bg8.png)
M
M
M
7
7
7
V
V
V
I
I
I
Z
Z
Z
6
On Board Peripherals
a. Rear side
1 serial port.
1 VGA port.
1 parallel port. (SPP/EPP/ECP mode)
Audio ports in vertical position.
1 RJ-45 LAN jack.
PS/2 mouse and PS/2 keyboard.
2 USB2.0 ports. (4 USB2.0 ports only support with South Bridge VT8237)
1 1394A Firewire ports. (Optional for Version 1.3, none for Version 8.0)
b. Front Side
1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes.
4 USB2.0 ports.
1 front audio header.
1 S/PDIF out header.
1 1394A Firewire ports. (Optional for Version 1.3, none for version 8.0)
Dimensions
ATX Form Factor: 22.1 X 24.5cm (W X L, f or v ersion 1.3)
19.4 X 24.4cm (W X L, for v ersion 8.0)
B. BIOS & Software
BIOS
Award legal BIOS.
Supports APM1.2.
Supports ACPI.
Supports USB Function.
Software
Supports Warpspeeder™, 9th Touch™, FLASHER™
Off ers the highest performance for Windows 98 SE, Windows 2000, Windows Me,
Windows XP, SCO UNIX etc.
Package contents
HDD Cable X 1
FDD Cable X 1
User’s Manual X 1
Fully Setup Driver CD X 1
USB 2.0 Cable X 1 (optional)
S/PDIF out Cable X 1 (optional)
Rear I/O Panel f or Micro ATX Case X 1 (optional)
IEEE 1394 Cable X 1 (optional, none for Version 8.0)
