Biostar M7VIZ [31/63] M m m 7 7 7 v v v i i i z z z

Note:

Because the overclock, overvoltage, and hardware monitor features are

controlled by several separate chipset, [ WarpSpeeder™ ] divide these

features to separate panels. If one chipset is not on board, the correlative

button in Main panel will be disabled, but will not interfere other panels’

functions. This property can make [ WarpSpeeder™ ] utility more robust.
