English
M7VIZ Features
A. Har dware
CPU
Prov ides Sock et A.
Supports single AMD
®
Athlon/ Duron Family processor.
Front Side Bus at 200/266/333 MHz.
Chipset
North Bridge: VIA KM400.
South Bridge: VIA VT8235CE/ VT8237.(optional)
Main Memory
Supports up to 2 DDR devices.
Supports SPD DDR 200/266/333/400 MHz (without ECC) DDR dev ices
Maximum memory size is 2GB.
Super I/O
Chip: Winbond W83697HF (Version 1.3).
ITE8705F (Version 8.0)
Slots
Three 32-bit PCI bus master slots.
One CNR slot. (only Ty pe B)
One AGP 8X slot.
On Board IDE
Supports four IDE disk drives.
Supports PIO Mode 4, Master Mode and Ultra DMA 33/66/100/133 Bus Master
Mode.
LAN PHY
Chip: VIA VT6103.
Supports 10 Mb/s and 100 Mb/s auto-negotiation
Half /Full duplex capability.
IEEE 1394 Chip (Optional for Version 1.3. None for Version 8.0)
Chip: VIA VT6307.
Supports 2 IEEE 1394 ports.
Detects connected dev ice ty pes and automatically configure data speed to 100,
200 or 400 Mbps.
On Board AC’97 Sound Codec
Chip: CMI9761A.
Compliant with AC’97 specification.
Supports 6 channels.
