Usage

The following figures are just only for reference, the screen printed in this user manual will

change according to your motherboard on hand.

[WarpSpeeder™] includes 1 tray icon and 5 panels:

1. Tray Icon:

Whenev er the Tray Icon utility is launched, it will display a little tray icon on the right side of

Windows Taskbar.
