Biostar NF4UL-A9 [11/64] Nf4 ultra a9

NF4 Ultra-A9

Step 3: Look for the black cut edge on socket, and the white dot on CPU

should point forwards this black cut edge. The CPU will fit only in

the correct orientation.

Step 4: Hold the CPU down firmly, and then close the lever to complete

the installation.

Step 5: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN

power cable to the JCFAN1. This completes the installation.
