Biostar NF4UL-A9 [8/64] B bios software

NF4 Ultra-A9

3 audio ports support 6 channels audio-out facilities (with

ALC655, optional).

PS/2

Mouse

PS/2

Ke y boa r d

Printer Port

COM1 COM2

(optional)

1394 Port

(optional)

USB *2

Connector

US B *2

Line-in/Rear

Line-out

MIC -in/

Center/

Left

B. BIOS & Software

BIOS

Award legal BIOS.

Supports APM1.2.

Supports ACPI.

Supports USB Function.

Bundled Software

Supports 9th Touch™, WINFLASHER™ and FLASHER™.

1.2 PACKAGE CHECKLIST

FDD Cable x 1

HDD Cable x 1

User’s Manual x 1

Serial ATA Cable x 1

Fully Setup Driver CD x 1

Rear I/O Panel for ATX Case x 1

S/PDIF Cable x 1 (optional)

USB 2.0 Cable x 1 (optional)

IEEE 1394 Cable x 1 (optional)

Serial ATA Power Switch Cable x 1 (optional)
