NF4 Ultra-A9

6.4 [WARPSPEEDER™] INCLUDES 1 TRAY ICON A ND 5 PANELS

1. Tray Icon:

Whenever the Tray Icon utility is launched, it will display a little tray

icon on the right side of Windows Taskbar.

This utility is responsible for conveniently invoking [WarpSpeeder™]

Utility. You can use the mouse by clicking the left button in order to

invoke [WarpSpeeder™] directly from the little tray icon or you can

right-click the little tray icon to pop up a popup menu as following

figure. The “Launch Utility” item in the popup menu has the same

function as mouse left-click on tray icon and “Exit” item will close

Tray Icon utility if selected.
