NF4 Ultra-A9
20
Onboard Parallel Port
This item allows you to determine access onboard parallel port controller
with which I/O Address.
The Choices: 378/IRQ7 (default), 278/IRQ5, 3BC/IRQ7, Disabled.
Parallel Port Mode
The default value is SPP.
The Choices:
SPP(default) Usin g Parallel port as Standard Printer P ort.
EPP Using P aralle l P ort as Enhanced Parallel P ort.
ECP Using Parallel port as Extended Capabilities Port.
ECP+EPP Using Parallel port as ECP & EPP mode.
ECP Mode Use DMA
Select a DMA Channel for the port.
The Choices: 3 (default), 1.
IDE HDD Block Mode
Block mode is also called block transfer, multip le commands, or multip le sector
read / write. If your IDE hard drive supports block mode (most new drives do),
select Enabled for automatic detection of the optimal number of block mode
(most new drives do), select Enabled for automatic detection of the optimal
number of block read / write per sector where the drive can support.
The Choices: Enabled (default), Disabled.
Power on Function
This option allows you to choose the different function to power on the computer.
The Ch o ice s: Ho t Ke y (default), Password, Mouse Move, Mouse Click, Any Key,
Button Only, Keyboard 98.
KB Power ON Password
Input password and press Enter to set the Keyboard power on
password.
Hot Key Power on
This option allows you to choose a hot key to power on.
The Choices: Ctrl-F1 (default), Ctrl-F2, Ctrl-F3, Ctrl-F4, Ctrl-F5, Ctrl-F6, Ctrl-F7, Ctrl-F8
