NF4 Ultra-A9
2
Dimensions
ATX Form Factor: 23.4cm (W) x 29.35cm (L)
Main Memory
Supports Dual Channel DDR.
Supports 8 banks in total.
Supports DDR333 and DDR400.
Maximum memory size is 4GB.
DIMM Socket
Location
DDR Module
To tal Memo r y
Size (MB)
DIMM1 128MB/256MB/512MB/1GB *1
DIMM2 128MB/256MB/512MB/1GB *1
DIMM3 128MB/256MB/512MB/1GB *1
DIMM4 128MB/256MB/512MB/1GB *1
Max is 4 GB.
DDR Installation Notice:
Please follow the table below to install your DDR memory
module, or the system may not boot up or may not function
properly.
“SS” represents Single Side DDR memory module.
“DS” represents Double Side DDR memory module.
Star sign “*” represents leave the DIMM socket empty.
DIMM1 SS/DS
*
SS/DS SS/DS
DIMM2
* * *
SS/DS
DIMM3
*
SS/DS SS/DS SS/DS
DIMM4
* * *
SS/DS
On-board IDE
2 on-board connectors support 4 IDE disk drives.
Supports PIO mode 5, Block Mode and Ultra DMA
33/66/100/133 bus master mode.
Serial ATA
4 on-board Serial ATA connectors support 4 serial ATA (SATA)
ports.
Compliant with SATA2.0 specification.
Data transfer rates up to 3Gb/s.
