Biostar NF4UL-A9 [25/64] Features and benefits

NF4 Ultra-A9

RAID 0+1:

RAID 0 drives can be mirrored suing RAID 1 techniques. Resulting in a

RAID 0+1 solution for improved performance plus resiliency.

nVI D IA

nForce 4

CK 8-0 4

Ul t ra

Block 2

Block 4

Block 6

Block 1

Block 3

Block 5

Block 2

Block 4

Block 6

Block 1

Block 3

Block 5

Features and Benefits

¾ Drives: Minimum 4, and maximum is 6 or 8, depending on the

platform.

¾ Benefits: Optimizes for both fault tolerance and performance,

allowing for automatic redundancy. May be simultaneously used

with other RAID levels in an array, and allows for spare disks.

¾ Drawbacks: Requires twice the available disk space for data

redundancy, the same as RAID level 1.

¾ Fault Tolerance: Yes.
