NF4 Ultra-A9
4
Gigabit Ethernet LAN
NVIDIA Gigabit MAC + VITESSE Gigabit PHY VSC8201.
Supports 10 Mb/s, 100 Mb/s and 1Gb/s auto-negotiation.
Half/Full duplex capability.
Supports personal Firewall setup.
Supports ACPI power management.
Supports NVIDIA StreamThru technology
- Isochronous controller paired with Hyper Transport results
in fastest networking performance
Security
NVIDIA Networking Processor.
NVIDIA Firewall technology
- Native firewall solution, protects the PC from intruders by
filtering unauthorized traffic.
Advanced features
- Remote access, configuration, monitoring
- Command line interface (CLI)
- WM I scri pts.
NVIDIA Active Armor
- Enhance network security, and providing users an
environment with both fast and secure.
Storage
NVIDIA RAID Technology
- RAID 0 disk striping for highest system and application
performance
- RAID 1 disk mirroring support for fault tolerance
Support for both SATA and ATA-133 disk controller
standards
- RAID 0+1 disk striping and mirroring for highest
performance with fault tolerance
