Parameter Description

VPN tunnel

IPX Series’ VPN service supports max 4 connections. Tunnel num can be tell

by the other side to which num of the tunnel can be connected. This option has

relative to “Remote VPN tunnel number”.

Tunnel name Type a human-friendly name for your new connection.

VPN service Decide to Enable or Disable this tunnel.

Remote VPN tunnel

number

The tunnel number of the remote site we connected. Verify that the tunnel

number of the remote site is correct or change as necessary, check with the

remote system’s administrator to make sure that they have given you

the right

tunnel num on the VPN

Remote IP or domain

Type in the valid Internet address or domain name of the remote IPX Series

machine you are trying to connect to.

Remote IP mode

Please open the drop down menu labeled to decide remote IP mode is fix or

float one.

Encryption

Please open the drop down menu labeled to enable or disable encryption on

the tunnel.

Encryption key

Please fill encrypted key the same as the remote IPX series machine. Note:

passwords are case sensitive!

Support IPX and

neighborhood

Please check “NetBIOS over TCP/IP” and “IPX/SPX” if that protocol is both in

use in the local and the destination (VPN) network, then you can open the

drop down menu labeled to decide whether use this function.

IPX VPN provides powerful VPN router feature and user-friendly web setup for SOHO & enterprises.

This IPX VPN provides four features as below.

1. It provides up to four sections of peer-to-peer VPN tunnels.

IPX VPN supports 4 channel of VPN resources. In other words, any IPX VPN could connect up to four

IPX VPN units.
