Calling party configuration

This is where you enter the details of all the VoIP servers that you want to communicate with. An IP

phone call involves two VoIP servers: your IPX-1000 and the VoIP server at the other end. Both VoIP

servers must be in the same mode when communicating with each other. Therefore, in addition to

setting up your own system properly, you must also advise the other party to set up their system with

the same mode. Here is a description on the three available modes.

Add Calling Party

Parameter Description

Seq No. Please assign a unique number to each server.

Name Please insert the name for your own reference.

Destination

From the drop down list, please

select a mode to use when communicating

with this server.

IPX Mode:

This mode is unique to IPX-

1000 and requires both parties to have static IP

address. If the other party also uses IPX-

1000, using this mode is highly

recommended but not mandatory. When two parties communicate in the IPX

mode, their systems know more about each other’s capabilities. This mode

offers better Off-Net controls.

GW Mode:

his mode requires both parties to have static IP address. This mode is

usually used when the other party uses an H.323 system other than IPX-1000.

GK Mode:

You must use this mode if at least one party does not have static IP address.

The call is made through a

Gatekeeper service with which both parties are

registered.

DONE

Clicking on the DONE button to add an entry. A new menu will appear for you to enter the other

server’s IP address or domain name.
