Parameter Description

Operation Mode

Your choices are P2P

mode and GK mode, as described above. If you select

the P2P mode, you don’t need to set up

any Gatekeeper related items

described below.

H323 ID Please insert the name for your own reference.

Out Call Priority (Toll

Restriction)

You can restrict the outward dialing capability with this function if you also set

up the Toll Table. The Toll Table

tells the system whether the dialed number is

local, Domestic long distance or international.

GK Password

Please insert

the password that you need to register with (login) the

Gatekeeper service. Consult with your Gatekeeper

service provider if you

don’t know.

GK IP

Please insert the IP address of your Gatekeeper service provider. C

onsult with

your Gatekeeper service provider.

GK Port

Please insert

the port used by the Gatekeeper service. Consult with your

Gatekeeper service provider.

GK time to live (min)

Gatekeeper searching time.

Vocoder Voice compression type.G.723.1 or G.729a.

VoIP gain

Alignment VoIP gain, default value is –3dB. For example, if IPX-

1000 results

echo when communicate with another VoIP device, you have to adjust

IPX-1000’s VoIP gain till the echo is disappear.

Port 1 ID, Port 2 ID

Please insert the ID for por

t 1 and 2. Consult with your Gatekeeper service

provider if you don’t know.

Note that, in general, each port ID must be unique.

DONE

Clicking on the DONE button to apply the changes.
