Planet IPX-1000 [9/79] Administration interface

4.Connecting power

· Plug the power supply into the IPX-1000.

· Plug the power cord into a power outlet. Three lights (“Power”, “24V”, and “80V”) on the front

panel will turn on, indicating that the system is up and running.

5. Check the LEDs

· The PWR LED should be ON.

· For each LAN (PC) connection, the LAN LNK/ACT LED should be ON (provided the PC is also

ON.)

· The WAN LED should be ON.

6. Connecting to the telephony devices

· Connecting to PSTN/CO line

Connect CO line(s) to IPX-1000’s line 1 and/or line 2. The “Line 1” and/or “Line 2” light(s)

on the front panel will turn on.

· Connecting to Telephone

Connect telephone(s) to Tel 1 ~ Tel 4 (Extension 1 ~ Extension 4)

Administration Interface

PLANET IPX-1000 provides GUI (Web based, Graphical User Interface) for machine management and

administration.

Connection of incorrect telephony devices to the ports on

the TIM can cause permanent damage to the TIM and/or IPX.

Note
