62
Pick up phone 121 1.IPX-1000 dial tone is heard.
2.the first LED will be at the green color in
Phone 1 of front panel.
Dial *6 1.Hear dial tone
Dial 4000 + 888 1.Du Du is heard
2.The first LED is lighting in LINE 1 of
VIP-400 front panel.
Dial 801
2.PBX communication is going
Ring back tone is heard Ext.801 is ringing
Case 2: IPX-1000 Phone 121 calls to PSTN number (02) 12345678 via VIP-400.
Human operation at IPX
Caller side
Equipment operation Human operation at
VIP Receiver Side
Pick up phone 121 1.IPX dial tone is heard.
2.the first LED will be at the green color in
Phone 1 of front panel.
Dial *6 Hear dial tone
Dial 4000 + 888 1.Du is heard
2.The first LED is lighting in LINE 1of
VIP-400 front panel.
Dial 0
1.VIP-400 is connected to PBX outside
call
PSTN dial tone is heard
1.IPX-1000 is connected to VIP-400
2.VIP-4000 is connected to PSTN
Dial 12345678 1.PSTN communication is going
Ring back tone is heard Phone 12345678 is ringing
