Planet IPX-1000 [7/79] Physical interfaces

Physical Interfaces

IPX-1000 is equipped with a WAN interface with 10/100 Mbps auto-negotiation capability, 4 LAN

Ethernet ports with 10/100 Mbps auto-negotiation, auto-MDI/MDI-X capability. In addition to the

LAN/WAN Ethernet interface ports, there is a 9-pin RS-232 interface port, four RJ-11 telephony

interface ports on the rear panel. Their functions are described below:

Port Label Function

RJ-45 LAN Connecting IPX to a 10/100 Mbps Ethernet network

RJ-45 WAN Connecting IPX

to a 10/100 Mbps Ethernet network / xDSL

/Cable modem for Internet access

9-pin RS-232 Console Factory use.

RJ-11 (Line1~2) PSTN/CO line Connected directly to the PSTN analog line/CO line.

RJ-11 (TEL1~4) Telephony Connected Telephone to PBX for voice communication
