Planet IPX-1000 [59/79] Chapter 5 voice communications

Chapter 5

Voice communications

Overview

There are several ways to make calls to desired destination in IPX-1000. In this chapter, we’ll lead you

step by step to establish your first voice communication via web browsers operations.

Default Configuration

Without any configuration, your IPX-1000 is come with following basic information.

Extension number:

Supposing you have one IPX-1000 connect to four telephones, just pick up phone 1 and dial ‘124’,

phone 4 should rings.

( G124 ð PBX ð local port #4ð (

)))

Ext 1: 121

Ext 4: 124

Ext 2: 122

Ext 3: 123
