Planet IPX-1000 [79/79] Appendix a ipx 1000 specifications

Appendix A

IPX-1000 Specifications

Model IPX-1000

Dimensions (mm) 215 (L) x 30 (H) x 132 (W)

Operating Temperature 0~50 degree C, 10~90% humidity

VoIP Standard H.323,

Compression G.723/G.729

Echo Cancellation G.165/G.168 25ms

Network Protocol: TCP/IP, NAT, DHCP, HTTP, DNS

Network Interface: LAN 4 * 10/100 Mbps RJ-45

Network Interface: WAN 1 * 10/100 Mbps RJ-45

Telephony Interface 6 RJ-11 (4 FXS for extension, 2 FXO for CO/PSTN line connection)

Power Adapter 12 V
